Upgraded to BT-70780T

SKU

BT-70780 (BB-2800/U)

Military #

BB-2800/U

NSN

6140-01-490-5372

Chemistry:

Li-ion

Typically used in FED (AN/PSG-7), SLGR (AN/PSN-10), PLGR (AN/PSN-11), SAGR (AN/ASN-169), CAM and ICAM.

Part number has been replaced. Please refer to BT-70780T.

• Single Wire Battery Communication
• UN/DOT 38.3 Rating: 33 Wh
• Comparable to: BA-5800/U
• Absolute State of Charge Indicator

Typically used in:
• SLGR or PLGR (AN/PSN-10 or -11)
• FED (AN/PSG-7)
• SAGR (AN/ASN-169)
• CAM and ICAM

Length: 5.1

Width: 1.4

More Information
SKU	BT-70780
Nominal Voltage	7.2V
Ah	Typical @ 2.0A 4.0
Maximum Voltage	8.4V
Operating Temperature	-20°C to +55°C (-4°F to +131°F)
Storage Temperature	-40°C to +40°C (-40°F to +104°F)
Connector	Flat Circular Contacts as per MIL-PRF-32-52/3
State of Charge Indicator	Yes
Battery Type	Rechargeable
