SKU
BT-70915-1/3AV
CES 1/3, 3.4 Ah
NSN
6140-01-673-9017
Chemistry:
Li-ion
3.4 Ah, Rechargeable Lithium-Ion Battery
Typically used to power portable optical devices.
- Complies with SMBus v1.1 and SBData v1.1
- Comparable to: BT-70915Ax, BT-70915-1/3Ax and BT-70915-2/3Ax
- Enhanced cold temperature performance
- Absolute state of charge indicator
- Tested and certified to meet requirements of battery safety standard IEC 62133
- CE Compliant
Dimensions
Length: 1.748 +/- 0.020
Width: 1.748 +/- 0.020
Height: 3.450 +/- 0.020
Weight: 0.5 lbs.
Other
| SKU | BT-70915-1/3AV |
|---|---|
| Nominal Voltage | 10.8V |
| Ah | 6.4 |
| Maximum Voltage | 12.6V |
| Operating Temperature | -32°C to +60°C (-25.6°F to +140°F) |
| Storage Temperature | -40°C to +55°C (-40°F to +131°F) |
| Connector | BT Designed Mating Connector |
| State of Charge Indicator | Yes |
| Battery Type | Rechargeable |
