SKU
BT-70716BV
MBITR PRC-148, 7.0 Ah
NSN
6140-01-679-4822
Chemistry:
Li-ion
7.0 Ah MAX Power, Rechargeable Lithium-Ion Battery
This is the best AN/PRC-148 built battery today. Run time is over 40% improvement over the standard commo shop AN/PRC-148 battery. Meets or exceeds all military rechargeable durability specifications. Works in all variants of the AN/PRC-148 & WAVE radio.
• MAX Power 8 Amp
• Communicates using a Single Wire DQ interface
• UN/DOT 38.3 Rating: 76 Wh
Typically used in:
• Wave Relay System
• AN/PRC-148
• TRC-9110
• Silvus StreamCaster 4200
Dimensions
Length: 2.6
Width: 1.6
Height: 3.4
Weight: 1.0 lbs.
Other
| SKU | BT-70716BV |
|---|---|
| Nominal Voltage | 10.8V |
| Ah | 7 |
| Maximum Voltage | 12.6V |
| Operating Temperature | -30°C to +60°C (-22°F to +140°F) |
| Storage Temperature | -40°C to +40°C (-40°F to +104°F) |
| Connector | Flat Contacts (bottom), 1/4-Turn (top) |
| State of Charge Indicator | No |
| Battery Type | Rechargeable |
| Smart Battery | DQ |
| Brenergy | No |
Some documents are available to logged in users only. Please log in or create an account to view.
Product Downloads
